The PATT™ Lighting Range

PATT 2013™

The fixture that started the family. Tim wanted stage lights that look as good on camera as the people they light, so he took inspiration from vintage broadcast luminaires and designed a 750 W tungsten softlight around a sleek, spun aluminium body.

Built by Robe around the readily available HPL lamp, it became a fixture of TV studios and concert stages – from The Graham Norton Show, X Factor and Britain's Got Talent to Gary Barlow, Robbie Williams, Paul McCartney and The Prodigy.

Source

750 W HPL tungsten lamp

Colour temperature

3,050 K

Reflector

550 mm parabolic aluminium

Size

691 × 695 × 324 mm

Weight

7.2 kg

Control

External dimmer

picklePATT™

The second fixture Tim created with Robe: all the charm of the PATT 2013 in a smaller, cuter package. A 575 W tungsten softlight in a 392 mm spun reflector, perfect for filling a set with warm eye candy where space is tight.

Source

575 W HPL tungsten lamp

Colour temperature

3,050 K

Reflector

392 mm parabolic aluminium

Size

520 × 531 × 241 mm

Weight

5.3 kg

Control

External dimmer

pixelPATT™

The first PATT with a colour-changing LED source: seven small PATT reflectors – one in the centre, six around it – in a super-slim brushed metal frame that keeps the curves of the originals.

Each cell is individually controllable, so it can fade like a tungsten lamp, run its own pixel effects or be mapped from a media server. Power and data come from a remote PATT Driver.

Source

7 × 40 W RGBW LED

Reflectors

7 × 200 mm, gold-brown

Colour

RGBW or CMY, 2,700–8,000 K, tungsten emulation

Control

DMX, RDM, Art-Net, sACN via PATT Driver

Size

959 × 870 × 158 mm

Weight

12.1 kg

PATT 2017™

The full-size PATT 2013 body with an LED heart. Seven 40 W RGBW LEDs light the gold-brown reflector, and each one can be controlled separately – so it can glow like warm tungsten or roll smooth rainbows and animations around the dish.

More environmentally conscious than the tungsten original, and driven from a remote PATT Driver over standard scroller cable.

Source

7 × 40 W RGBW LED, individually controllable

Reflector

550 mm parabolic aluminium

Colour

RGBW or CMY, 2,700–8,000 K

Control

DMX, RDM, Art-Net, sACN via PATT Driver

Size

680 × 695 × 356 mm

Weight

10.3 kg

onePATT™

A single high-powered RGBW LED in a super-slim 200 mm retro frame weighing just 1.6 kg. Use one as a practical, or build walls and matrices of them – up to seven run from each PATT Driver and they can be pixel-mapped as one big canvas.

Source

40 W RGBW LED multichip

Reflector

200 mm, gold-brown

Colour

RGBW or CMY, 2,700–8,000 K

Control

Up to 7 per PATT Driver

Size

321 × 309 × 150 mm

Weight

1.6 kg

HolyPATT™

Based on the PATT 2013, HolyPATT is pure scenic warmth: a vintage-style LED filament lamp glowing at 1,800 K inside a see-through gold-brown reflector. Convection cooled and completely silent, with ultra-smooth dimming – made for set dressing and atmosphere.

Source

4 W LED vintage filament lamp

Colour temperature

1,800 K

Reflector

496 mm see-through, gold-brown

Power

4 W

Size

680 × 695 × 210 mm

Weight

7.2 kg

MolyPATT™

The picklePATT-sized version of the HolyPATT: the same 1,800 K vintage filament glow and see-through gold-brown reflector in a smaller, lighter body. Silent and ideal for dressing sets in numbers.

Source

4 W LED vintage filament lamp

Colour temperature

1,800 K

Reflector

353 mm see-through, gold-brown

Power

4 W

Size

520 × 532 × 159 mm

Weight

4.8 kg

SVOPATT™

The biggest leap in the family: nine PATT-inspired modules in one bold frame, each with its own motorised zoom, RGBW pixels and a white strobe at its centre. Over 75,000 lumens for blinding audience hits, sweeping beams and pixel-mapped effects – yet quiet enough for TV studios.

Link them together and they build into walls and curtains of light.

Source

9 modules of 7 × 40 W RGBW LED + white strobe

Output

75,000 lm

Zoom

3.8°–50° per module

Noise

18 dB(A) in quiet mode

Size

1005 × 435 × 216 mm (without yoke)

Weight

39.7 kg

SVB1™

Built on the SVOPATT lineage, SVB1 puts a single SVOPATT-style module into a compact, fast moving head with continuous pan and tilt. Seven RGBW cells around a central pixel with a 200 W white strobe give 11,000 lumens, a 3.8° to 50° zoom and full pixel mapping – beam, wash and effect in one 7.2 kg fixture.

Source

7 × 40 W RGBW LED + 200 W white strobe

Output

11,000 lm

Zoom

3.8°–50°

Movement

Continuous pan and tilt

Noise

18 dB(A) in quiet mode

Weight

7.2 kg

SVOPATT™ Classic

Created in answer to demand for a simpler SVOPATT. Nine modules of RGBA LEDs with a tight fixed 4° beam and quick-swap SvoFrost diffusers, delivering over 12,500 lumens. A bold scenic element on its own, and in multiples a continuous light curtain – still ultra quiet for broadcast.

Source

9 modules of 6 × 40 W RGBA LED

Output

12,500 lm

Beam

4° fixed, SvoFrost diffusers 5°–32°

Noise

18 dB(A) in quiet mode

Size

1005 × 435 × 216 mm (without yoke)

Weight

36.3 kg
